Product Family Stainless Steel Quality Class 2
The Ganter product range includes a large number of standard parts made of high-quality, non-rusting stainless steels. Thanks to their outstanding material properties, these are used in a wide array of industries. Their corrosion and rust resistance in particular contributes to the value stability and longevity of machines and equipment.
For easier differentiation, the stainless steels used by Ganter are divided into stainless steel quality classes:
Stainless Steel Quality Class 1
Stainless Steel Quality Class 2
Stainless Steel Quality Class 4Show detailed information on the stainless steel quality classes
Show all stainless steel products
Product description
Leveling feet GN 20 with extended adjusting range are suitable for use in hygiene areas.
The bottom seal protects the area beneath the foot plate from dirt. For this, the foot must be pressed down by the weight of the machine. The sealing ring above the adjustment sleeve enables fastening without dead space. Due to the wiper or the joint sealing ring, the moving components are sealed against the environment.
The high quality finish prevents adherence of dirt and facilitates cleaning.
The values listed in the table for static load capacity refer to a purely vertical load in relation to the leveling foot. Under normal operating conditions bending loads or angular loads are not uncommon and result in a reduction of load capacity, which must be taken into consideration.
Specification
Spindle / Screw-in sleeve / Foot plate
Stainless steel AISI 304
Turned
Seals
- FDA compliant material
- Blue
- Sealing ring
NBR, hardness 70 ±5 Shore A - Wiper
TPU, hardness 95 ±5 Shore A - Joint sealing ring
HNBR, hardness 85 ±5 Shore A - Bottom seal
Silicone, hardness 85 ±5 Shore A
Cover cap
TPU, hardness 95 ±5 Shore A
- FDA compliant material
- blue
RoHS
