GN 664.1 Filler Strainers for Side Mounting


GN 664.1 Filler Strainers for Side Mounting Thread d<sub>1</sub>: G 1 1/4
ELESA original design
code: PLRF+C

Product description

Information

Filler strainers GN 664.1 are available with mounting flange for threaded or bayonet (BA) connection. Filler strainers prevent the ingress of coarse impurities during the refilling process.

The side flange is fitted with 7 screws M6 on the wall of the tank. When installing the flange it is important that these are not overtightened (torque max. 8 Nm) to prevent deformation of the flange and possible weakening of the sealing.

The mounting screws M6 for the side flange are not included.

Specification

Threaded flange
Plastic
  • Glass fiber reinforced
  • Black, matte finish

Filler strainer
Plastic (Polypropylen PP)
  • Glass fiber reinforced
  • Temperature resistant up to 90 °C
  • Black, matte finish

Flange for fitting bayonet
Steel, zinc plated, blue passivated
Seal cork
Impregnated with rubber

RoHS

On request

Mounting flange without the filler strainer

Technical drawing

3D
Hide technical drawing
GN 664.1 Filler Strainers for Side Mounting sketch

Article options / Table

Show / Hide columns
d1
Thread
d2
Bayonet
BA
d3d4h1h2l1l2s
G 1 1/4BA 3949718921481177

Build & Price

Open 3D configurator
Thread d1
Bayonet d2

Front view with hole pattern

Sketch GN 664.1 bore

Selected Part (How to order)

Total (net)
31,77
plus VAT 6,04 €
gross 37,81 €
In stock
Weight: 0,300 kg
If this article is new in our product range, it may happen that details concerning weight are as yet not listed.
If you do need weight details, please contact our Sales Department!
Phone +49 7723 6507 - 0
RoHS: Yes
This article is RoHS-compliant in application of Annex III., which means it complies with EU Directive 2011/65/EU, including extension (2015/863/EU), for restricting the use of certain hazardous substances in electrical and electronic devices. The Directive regulates the use of hazardous substances in devices and components. The implementation in national law is summarily described with RoHS(Restriction of (the use of certain) hazardous substances).
Please note our order discounts.
With a total value (net) per order:
from 175,00 € -> 10 % discount
from 275,00 € -> 20 % discount
from 375,00 € -> 30 % discount

Surcharge for small volume purchases:
-> 15,00 Euro
for value of goods less than 25,00 €
-> 10,00 Euro
for value of goods from 25,00 to 50,00 €
All prices in accordance with our price list No. 55, valid from 1 September 2022, plus VAT only valid for Germany.
