GN 953.1 Spacer plate for position indicators GN 953


ELESA original design
code: BS52R

Product description

Information

The previous position indicators GN 952 are replaced by position indicators GN 953, they are dimensionally reduced compared to GN 952.

The spacer plate GN 953.1 is used as adapter in case the dimensions on the machine body are applied to match the previous model GN 952.

The bore holes Ø 2,2 are used for the machine-side fastening with e.g. socket button head self-tapping screws in accordance with DIN ISO 7049.

Specification

Plastic (Polyamide PA)
black, matte

RoHS

Technical drawing

3D
Hide technical drawing
GN 953.1 Spacer plate for position indicators GN 953 sketch

Article options / Table

Build & Price

Open 3D configurator

Selected Part (How to order)

Total (net)
1,57
plus VAT 0,30 €
gross 1,87 €
In stock
Weight: 0,018 kg
If this article is new in our product range, it may happen that details concerning weight are as yet not listed.
If you do need weight details, please contact our Sales Department!
Phone+49 7723 6507 - 0
RoHS: Yes
This article is RoHS-compliant in application of Annex III., which means it complies with EU Directive 2011/65/EU, including extension (2015/863/EU), for restricting the use of certain hazardous substances in electrical and electronic devices. The Directive regulates the use of hazardous substances in devices and components. The implementation in national law is summarily described with RoHS(Restriction of (the use of certain) hazardous substances)).
Please note our quantity discounts.
With a total value (net) per order:
from 175,00 Euro -> 10 % discount
from 275,00 Euro -> 20 % discount
from 375,00 Euro -> 30 % discount
With a total value (net) per order:
All prices in accordance with our price list No. 52, valid from 1 May 2019, plus VAT only valid for Germany.
